| Connector Type | Receptacle, Male Pins |
| Number Of Positions | 10 |
| Qualification | MIL-5015 |
| Shell Size – Insert | 18-Jan |
| Mounting Type | Free Hanging (In-Line) |
| Termination | Solder Cup |
| Fastening Type | Threaded |
| Orientation | N (Normal) |
| Primary Material | Metal |
| Shell Material | Aluminum Alloy |
| Shell Finish | Olive Drab Chromate over Cadmium |
| Contact Finish – Mating | Silver |
| Color | Olive Drab |
| Features | Backshell |
| Shielding | Unshielded |
| Operating Temperature | -55°C ~ 125°C |
⚠️ Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
MS3101A18-1P
Manufacturer: Amphenol Industrial Operations
Part Number: MS3101A18-1P
Description: 10 Position Circular Connector Receptacle, Male Pins Solder Cup
Datasheet: MS3101A18-1P – Datasheet
$29.93
| Quantity | Price |
|---|---|
| 5 | $29.93 |
| 10 | $29.07 |
| 25 | $27.88 |
| 50 | $27.14 |
| 100 | $26.60 |
| 250+ | $26.09 |
